Free Residential House Design Prefabricated Dome Houses Garden Studio

Free residential house design prefabricated dome houses Product Application prefabricated dome houses garden studio is formed by the main framework through linking up the H beam, C purline, Z purline steel components. Roof and wall using a variety of panels together with other components such as...

Detailed description

Free residential house design prefabricated dome houses

p201704051154017547224(001).jpg  p201704051301132647198(001).jpg

Product Application

prefabricated dome houses garden studio is formed by the main framework through linking up the H beam, C purline, Z purline steel components. Roof and wall using a variety of panels together with other components such as windows and doors. The steel building has the advantages of wide span, high strength, light weight, low cost, temperature protection, save energy, beautiful appearance, short construction time, good effect of insulation, long using life, space-efficient, good seismic performance, flexible layout, etc.

Specifications:



Galvanized steel tube steel frame (80 * 80 * 3mm 60 * 40 * 2mm) + 75mm EPS sandwich panel + Asphalt tiles

75mm EPS sandwich panel, galvanized steel sheet 0.4mm, 12 kg / m³ Density EPS

1.2mm antisepsis Waterproof PVC Decorative panel

2050mm*800mm Steel Outer Door, 800*2100mm EPS sandwich panel door to bedroom,700mm*2100mm EPS sandwich panel for bathroom

1600mm * 1880mm / 2 units

The windows are Double Glass with 5mm.
5mm+6mm+5mm

1200mm *1880mm/1 unit

1200mm*930mm/2 units

600mm*930mm/1 unit

Ceramic Tile 600mm * 600mm for bedrooms, kitchen, living room and Porch, Ceramic bathroom tiles.

EPS sandwich panel structure

1.) for galvanized steel sheet Surface

2.) for the polystyrene Thermal insulation Core material

Steel Plate Thickness

0.4mm, PPGI

Panel Thickness

75mm

Effective width

950 / 1150mm - wall panel or the roof of Heaven

Length

According to the measure of the Wall, ceiling and roof of the Sky

The density of polystyrene

12KG/m³

Colour

White

Thermal transmittance

0.038-0.043W/M2.K

The intensity of the glued

≥0.10MPa

Burning Performance

B2

The Performance of Detachment

≥85%

The intensity of pressure against

≥69KPa

The hygroscopic rate

3.9%

Noise resistant

21.5  R(dB)

The Life of panel

45 years

Disaster degree

6 ~ 7 degrees

To wind Resistance

23 m/s




Main Features

1)Enviromental friendly

2) Lower cost and maintenance

3) Long using time up to 50 years

4) Stable and earthquake resistance up to 9 grade

5) Fast construction, time saving and labor saving

6) Good appearance

Our service:

Pre-Sale Service

  • Consultant service (Answering client's questions)

  • Primary design plan(Free)

  • Assisting client to choose suitable construction plan

  • Price calculation

  • Business&technology discussion

Sale Service

  • Submission of support reaction data for foundation

  • submission of construction drawing

  • Providing requirments for embedding

  • Construction Manual

  • Fabrication & Packing

  • Statistical table of material

  • Delivery

  • Other requirements by Clients

After-Sale Service

  • Service of installation Supervision

  • Instruction for using after installation completed
